Central Fume Extractor Central Series Dust Purifier

KSDC-6102
KSDC-6103
KSDC-6104
KSDC-8604A/A1
KSDC-8604B/B1
KSDC-8609B/B1
KSDC-8606B/B1
KSDC-8609B2
KSDC-8612B/B1
KSDC-12004
KSDC-12006
KSDC-12009
KSDC-120012
KSDC-120016
KS120-GP02G1/G2
KS120-GP03G1/G2

Central Fume Extractor

應用場景APPLICATION

Application: Applicable for various welding, grinding workshop, welding center, robot welding line and plasma laser cutting blanking production line etc.
焊接、打磨車間
焊接中心
機器人焊接線
等離子激光切割下料生產線

產品特性FEATURES

Features: ①Compact and reasonable structure design

②Convenient dust removal, fully automatic dust removal, to ensure the continuity and efficiency of production.

③Dust collection, container loading and unloading is convenient, the connection with the filter funnel is sealed, no dust leakage.

④Intelligent control, optional automatic inverter, remote linkage function

⑤PLC control system control, humanized design of operation panel, easy to use

⑥Adopting imported high-quality polyester filter material, and the surface of the filter material is covered with a high-precision PTFE membrane, which has higher filtration accuracy and higher filtration efficiency.


工作原理WORKING

Central Fume Extractor

During the purification system working, the dust enter the purification system through suction pipeline, the filter cartridge of the air inlet inside the purification system adopts stainless steel mesh sintered PTFE membrane filter material, which can intercept the large particles spark and flammable substances timely, which greatly improve the service life of the filter cartridge. Intercept and buffer the large particle dust that moves and splashes quickly with the airflow in the pipeline, then be separated directly and fall in to the dust collection bucket below.


Fine dust will slow down immediately after entering the purification system, and disperses the airflow with deflectors, which will avoid residual sparks and airflow enter the main filter cartridge; this product adopts international advanced PTFE membrane-coated filtration technology, with a high efficiency filtration, and keep a high air flow condition, when the wind resistance reaches a certain value and affecting the suction volume, the control system automatically opens the solenoid valve in turn, through the rotor type automatic rotating dust cleaning device in the filter cartridge, perform automatic blowback cleaning, which makes the dust removal on the surface of the filter cartridge more thorough and clean, always keep the dust collector with a constant suction volume. After the blowback cleaning, the dust fall into the dust collection bucket automatically.

產品參數PRODUCT


規格/型號KSDC-6102KSDC-6103KSDC-6104

61系列



入口風量Air Flow Of Treatment(m3/h)2400土1002600土1004000土100
電機功率Motor Power(kW)1.52.23.0
電壓Working(V) /頻率Voltage(Hz)3x380/503x380/503x380/50
清灰方式Cleaning Way全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰
壓縮空氣Compressed Air (Mpa)0.5~0.60.5~0.60.5~0.6
過濾效率Filtration Efficiency≥99%≥99%≥99%
噪音值Noise Level (dB)≤75士5≤75士5≤75士5
外形尺寸(W×D×H)Dimension(mm)720×700×1745900×850×17751100×800×2000
整機重量Weight (kg)225土10275土10435土10
濾筒數量(PCS)234





規格/型號KSDC-8604A/A1KSDC-8604B/B1KSDC-8606B/B1KSDC-8609B/B1KSDC-8609B2KSDC-8612B/B1

86系列

入口風量Air Flow Of Treatment(m3/h)4500/6500土3004500/6500土3006500/9500土5006500/9000土50012000土50018000/20500土500
電機功率Motor Power(kW)5.5/7.55.5/7.57.5/117.5/111518.5/22
電壓Working(V) /頻率Voltage(Hz)3x380/503x380/503x380/503x380/503x380/503x380/50
清灰方式Cleaning Way全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰
壓縮空氣Compressed Air (Mpa)0.5~0.60.5~0.60.5~0.60.5~0.60.5~0.60.5~0.6
過濾效率Filtration Efficiency≥99%≥99%≥99%≥99%≥99%≥99%
噪音值Noise Level (dB)≤72士5≤72士5≤75士5≤75士5≤75士5≤75士5
外形尺寸(W×D×H)Dimension(mm)1100×1100×27501170×1670×21501620×1750×2150

1900×2150×2400

  1800×2000×2500

1900×2150×24002250×2400×2400
整機重量Weight (kg)730/750土20750/780土201050/1120土201420/1550土201875土202450/2490土20
濾筒數量(PCS)4469912





規格/型號KSDC-12004
KSDC-12006KSDC-12009KSDC-12012KSDC-12016

120系列

入口風量Air Flow Of Treatment(m3/h)5000/6500/8000/12000土5008500/12500/16000土50021000/24000/28000土50030000/36000土50030000/36000/43000土500
電機功率Motor Power(kW)4/5.5/7.5/117.5/11/1518.5/22/3030/3730/37/45
電壓Working(V) /頻率Voltage(Hz)3x380/503x380/503x380/503x380/503x380/50
清灰方式Cleaning Way全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰全自動旋翼清灰
壓縮空氣Compressed Air (Mpa)0.5~0.60.5~0.60.5~0.60.5~0.60.5~0.6
過濾效率Filtration Efficiency≥99%≥99%≥99%≥99%≥99%
噪音值Noise Level (dB)≤75士5≤75士5≤78士5≤78士5≤78士5
外形尺寸(W×D×H)Dimension(mm)1160×960×36001160×1320×36001570×1320×38001570×1680×38001990×1680×3800
整機重量Weight (kg)860土20960/960/990土201780土201780土202150土20
濾筒數量(PCS)4691216




規格/型號KS120-GP02G1/G2
KS120-GP03G1/G2

激光120系列

入口風量Air Flow Of Treatment(m3/h)3500/50006000/8000
電機功率Motor Power(kW)3/45.5/7.5
電壓Working(V) /頻率Voltage(Hz)3x380/503x380/50
清灰方式Cleaning Way全自動旋翼清灰全自動旋翼清灰
壓縮空氣Compressed Air (Mpa)0.5~0.60.5~0.6
過濾效率Filtration Efficiency≥99%≥99%
噪音值Noise Level (dB)≤72士5≤75士5
外形尺寸(W×D×H)Dimension(mm)920×850×11751100×1100×2750
整機重量Weight (kg)360土5730/750土20
